Specification | 1 Disk 16CH NVR,H.265 |
Model No. | CV-NVR2016A |
System Structure | Embedded LINUX design,pure hardware decode,watchdog,hard disk storage,HDMI HD display,IP network video access. |
Main processor Hi3536D; | |
Video Input | Support 8ch*4K,16ch 5MP/20ch 4MP HD IPC access, each channel support dual stream access, support auto search,add,recording, preview and without debugging; |
Access bandwidth 80Mbps; | |
Video Output | 1channel HDMI output,1 channel VGA output,homology with HDMI,support |
Support videolink client preview,APP preview and seconds connection | |
Video recording resolution | Support 3840×2160 max |
Video Capacity | Support H.265+/H.265/H.264 decoding; |
NVR local recording playback support 1CH 8MP/4ch 4MP | |
Audio | Standard G.711, support audio and video recording,support HDMI output channel preview and playback audio and video, Videolink audio and video preview and playback; |
Storage | 1*SATA hard disk interface,support 8TB capacity; |
Support schedule record, motion detection linkage record; | |
Support external USB storage devices (such as ordinary U disk, mobile hard disk) backup; | |
User | Local maximum support for 16 users; |
Network Interface | 1*RJ45 Ethernet interface, support 10/100M self-adaption;support TCP/IP, IPv4, DHCP, NTP, RTSP, ONVIF, P2P, SMTP and so on protocols; |
Peripheral Interface | 2*USB2.0 interface(rear); support for the mouse, USB upgrade, import and export; |
Front Panel | 1* power,1*record,1*network indicator light; |
Business Functions | Support preview/recording/forward/remote service, support alarm linkage, support Videolink client remote control software; support videolink cloud service; |
Working Temperature | -10℃～＋55℃ |
Working Humidity | 10%～90% |
Power Supply | DC +12V/2A power |
Optional | Support buzzer |
