lProfessional design for HD network camera, small, beautiful and delicate, best for home security.
lMaterial: aluminum alloy, innovative patented heat dissipation structure, make HD camera can works well under high temperature.
l5.0 megapixel
lAdvanced digital signal processing technology, high brightness imported SMT IR source, show the best HD video effects in both day and night environment.
l5.0 Megapixel HD CS lens+ IR-CUT auto switch in day and night, 2.8-12mm Auto lens
l36 IR LED, effective night vision distance is 30m, excellent performance in dark environment.
lSupport 3D DNR, auto white balance, auto electronic shutter, auto electronic gain, real color reproduction, high resolution image.
lONVIF protocol, can provide the SDK.
Optional back-end products for the system:
IE browse software, P2P HD remote monitoring management software (one key realize remote control without complicated settings), Embedded HD NVR, NVR control keyboard, CMS HD network surveillance platform management software, High-definition surveillance analysis software.
Model: | CV-XIPAT927HWD26 | ||
Camera | Imaging sensor: | 5.0MP,H.265+,Mstar SSC377D+GC4653,1/3″CMOS | |
Scanning mode: | Progressive scanning | ||
Illumination: | color 0.01Lux@F1.2,black/white:0.005Lux@F1.2, IR on 0 lux | ||
Lens: | Standard with 5MP Auto Focus Motorized Lens 2.8-12mm | ||
Day and night switch: | IR-CUT dual optical filters auto switch in day and night | ||
DNR: | 3D-DNR | ||
IR source: | 36pcs IR Led | ||
Effective night vision distance: | 30 meters (measured value without light condition) | ||
P2P | YES | ||
WDR | 128db | ||
S/N Ratio | 50db | ||
Privacy mask | 4 | ||
shutter speed | 1/(10-10000)s | ||
Email function | YES | ||
FTP | YES | ||
Standard compression | Image compression: | H.264 | |
Video compression: | H.265+/H.265/H.264, support dual-stream, AVI format; support stream 32Kbps ~ 3.5Mpbs adjustable;support CBR/VBR | ||
Image | Max image size: | 2592X1944 | |
Frame rate: | 2880*1620@25fps,2560x1440@25fps,3MP/2048*1536@20fps、1080P/720P/D1@25fps | ||
Function | Interface protocol: | HTTP/RTSP/FTP/PPPOE/DHCP/DDNS/NTP/ONVIF2.6 | |
Intelligent alarm: | Humanoid detection,Motion detection, shadow alarm, network cable break, IP address conflict | ||
POE | YES (optional),IEEE802.3at/af Standard PoE/IN:37-57V(15.4W), DC/OUT:12V/1A(12.95W) | ||
Lightning Protection | Power, network, POE comprehensive lightning protection, in line with national standards GB/T17626.5, | ||
features | Support WEB configure, support for OSD, support video transmission,support mobile surveillance, support for mobile detection alarm center after the screen pop-up reminders and linkage; supports JPEG capture; provide perfect the SDK development package; | ||
Basic parameter | Power input: | DC 12V±10% | |
Power consumption: | 1W (IR off) / 9.5W (IR on) | 1.1W / 9.6W (IR on) | |
Work environment: | -40℃ ~ 85℃, humidity is less than 95% (no condensation) | ||
